Geothermal Energy in India (Dr P Dhamija, Dr S K Bharadwaj and Dr BMS Bist Ministry of New and Renewable Energy)
Background
|
G |
eothermal energy is heat stored in the deep interior of the earth. This thermal energy can be used for producing electricity and also for direct heat applications. In the last few decades, there has been an increasing use of geothermal energy all over the world.
Geothermal energy is found to be are liable and flexible renewable energy resource, which is economically competitive with other forms of energy. Geothermal power plants are modular and can be installed in incremental units as needed. Very small-scale kilowatt level geothermal power plants are also feasible. Geothermal energy has a large net positive impact on the environment and power from these plants is available continuously.
Besides, low heat geothermal sources can be used directly for green house, space heating, refrigeration, and for other industrial uses. The use of geothermal energy, however, has certain limitations as it may cause some pollution of land and air due to certain dissolved gases.
Technology
Geothermal resources can be of different types viz. Hydrothermal, Geo-pressured, Hot-dry rock and Magma. At present, the technology for economic recovery of energy is available only for hydrothermal resources and is being developed for other types of geothermal resources.
The technology to tap geothermal energy for power generation is based on the temperature of the hydrothermal reservoir/resource. High temperature geothermal reservoirs containing water and/or steam can provide steam to directly drive steam turbines and electricity generation plants. The power plants based on these high temperature resources are of two types: single flash steam power plant and binary cycle power plant.
Medium temperature resources are normally hot water with temperature ranging from 100–200°C. The most common technology for utilizing such resources for power generation is the binary cycle technology. A combination of conventional steam turbine technology and binary cycle technology can be used for moderate to low temperature resources.
Direct use applications are where geothermal heat is used directly rather than for power generation and the technology is built around the extraction of heat from relatively low temperature i.e. less than 150°C geothermal resources, using the heat exchanger, which extracts the heat from hot geothermal fluids. Geothermal heat can also be used for air conditioning and refrigeration applications through a geothermal heat pump.
The basic technologies for using hydrothermal resources are described in Table 1.
Table 1 - Basic Technologies for using Hydrothermal Resources
|
Reservoir Temperature |
Reservoir Fluid |
Common Use |
Technology commonly chosen |
|
High Temperature >220°C |
Water or Steam |
Power Generation Direct Use |
Flash Steam; Combined (Flash and Binary) Cycle Direct Fluid Use: Heat Exchangers Heat Pumps |
|
Intermediate Temperature 100–220°C |
Water |
Power Generation Direct Use |
Binary Cycle Direct Fluid Use: Heat Exchangers Heat Pumps |
|
Low Temperature 50–150°C |
Water |
Direct Use |
Direct Fluid Use; Heat Exchangers; Heat Pumps |
International Status
The worldwide use of geothermal energy as an alternative source of energy is increasing, due to reduced levels of environmental pollution as compared to fossil fuels. Today, many countries are using geothermal energy to generate electricity and for direct heat applications (Table 2).
The total global installed geothermal capacity for power generation in 2005 was over 8900 MWe and 27825 MWt for non-electrical purposes. The most common non-electric uses worldwide (in terms of installed capacity) are heat pumps (33%), followed by bathing (29%), space heating (20%), greenhouses (7.5%), aquaculture (4%), and industrial processes (4%).
The largest users of geothermal energy resources (both direct and indirect) are
Table 2- World Geothermal Power Scenario
|
Country |
Installed capacity (MW) (2005) |
|
USA |
2544 |
|
Philippines |
1931 |
|
Mexico |
953 |
|
Indonesia |
797 |
|
Italy |
790 |
|
Japan |
535 |
|
New Zealand |
435 |
|
Iceland |
202 |
|
Costa Rica |
163 |
|
El Salvador |
151 |
|
Kenya |
127 |
|
Russia |
79 |
|
Nicaragua |
77 |
|
Guatemala |
33 |
|
China |
28 |
|
Others (9 countries) |
67 |
Indian Status
Potential
As a result of various resource assessment studies/surveys, 340
The hot springs present in the country are grouped into seven provinces: Himalayan-Puga Chhumthang Province (ii) SohanaValley (iii) Cambay Basin (iv) SonNarmada lineament belt (v) West Coast (vi) Godavari basin and(vii) Mahanadi basin.
Utilisation
Geothermal exploration carried out in
Table 3 Potential Geothermal Provinces of
|
Provinces |
Surface T° C |
Reservoir T° C |
Heat flow (mW/m2) |
Thermal Gradient (°C/km) |
|
Himalayan |
>90 |
260 |
468 |
100 |
|
Cambay |
40-90 |
150-175 |
80-93 |
70 |
|
West Coast |
46-72 |
102-137 |
75-129 |
47-59 |
|
SONATA |
60-95 |
105-217 |
120-290 |
60-90 |
|
Godavari |
50-60 |
175-215 |
93-104 |
60 |
Source: D. Chandrasekharam, Feb.2000 IBC Conference ‘Geothermal Power Asia 2000’
Projects
The Programme of Geothermal Energy was transferred to the Ministry of New and Renewable Energy from the Ministry of Power in1988. Since then, the Ministry has been promoting development and utilization of geothermal energy for power generation and direct heat applications. The main achievements are as follows:
An experimental geothermal power plant of 5 kW capacity was set up at Manikaran in Himachal Pradesh. A cold storage plant was also constructed in Manikaran area to utilize geothermal energy at 90°C for preserving vegetables and fruit grown in that area.
An R&D project was undertaken by Regional Research Laboratory (RRL),
§ A Pre-feasibility Report on Development of Geothermal Fields in Puga for power generation was prepared by NHPC.
§ MT studies were assigned to NGRI,
I Puga Geothermal Field
a) Presence of a geothermal reservoir at a depth of about 1.5 to2 km.
b) The estimated depth of geothermal reservoir is about 4 to 5 km.
c) From the correlation of the anomalous conductivity of the reservoir and the measured temperature of the boreholes and based on regional heat flow values, the estimated temperature of the deep geothermal reservoir is 200–250°C
II Tatapani Geothermal Field
a) The Tatapani hot spring area is underlain by a highly conductive sub-surface section related to a major geothermal reservoir.
b) The estimated temperature at deeper levels (3 km) is about 260°C.
c) The thickness of high resistive crust in the region is about 6 to8 km towards southern side of the study area and is about 10 km towards north. Regionally, the conductive Tatapani hot spring zone falls between these two upper crustal blocks of varying thickness.
§ Magneto-telluric investigations in the geothermal field of Surajkund in Jharkhand, Badrinath-Tapovan in Uttarakhand and Satluj-Beas and
The MNRE is giving greater thrust on exploration and harnessing of
Concluded
Courtesy: Akshay Urja, Volume 1, Issue 2 (September– October 2007)
The Future of Liquid Biofuels for APEC Economies (part –VIII)
Continued from Volume V, Issue No. 8…
Next Generation Biofuels
|
T |
he
Second generation (Gen-2) biofuels are something of a misnomer, in that the term is applied indiscriminately to both resources and end use fuels. From the resource side, the Gen-2 potential is in non-food crops - in the immediate future from non-edible oils for diesel replacement and lignocellulosics (wood and straw) for both gasoline and diesel replacement. However, up to date the suggested biofuel products are distinctly Gen-1 with large R&D programs in new oil crops such as Jatropha for biodiesel, and ethanol from the carbohydrate portion of lignocellulosics for gasoline replacement. Gen-2 biofuels would more likely be much more fungible with the hydrocarbon economy. For example renewable diesel a hydrogenated lipid or fatty acid has much better temperature compatibility and miscibility criteria with regular diesel. Fischer Tropsch Liquids (FTL) produced from renewable resources would be indistinguishable from their fossil counterparts in end use applications. Other suggested Gen-2 biofuels include butanol, and various oxygenates derived from aldehydes and acids that can be produced from biomass carbohydrates or aromatics from the lignin component of lignocellulosics.
There are as yet no Gen-2 demonstration plants operating with lignocellulosic feedstocks. Several are either in the late planning or construction stage. The needed investment in Gen-2 is projected to be far higher per annual unit of production than sugarcane ethanol or starch based ethanol with energy efficiencies that will likely be a lower EROI against sugarcane ethanol, but with equal or better GHG offsets.
Conclusions
Biofuels received extensive attention in the APEC economies during the past few years, and their production and consumption has increased remarkably in response to major concerns about energy security, urban air quality, rural economic development, and most recently greenhouse gas offsets. The continuing growth of biofuels in the APEC economies is subject to a number of risk factors. For example, increasing biofuels production at a time of generally increasing commodity prices since 2000 has brought biofuels in general into controversy, illustrated by newspaper headlines on “fuel vs. food”. Especially in the early part of 2008 when food prices started to rise rapidly and some equated the climate change policy as being in opposition to food security if it is based on the first generation biofuels derived from food and feed commodities. The increase in the price of food commodities has already caused delays in the implementation of previously announced RFS programs in for example
All of these factors collected together show that the biofuels future has to address several risks. For Gen-1 biofuels there are few technology risks related to their production. While there is little risk with the accepted levels of fossil fuel substitution by biofuels, the current levels of 5% for biodiesel and generally 10% for ethanol in gasoline are insufficient to make a major contribution to offsetting GHG. Moving beyond these levels of fuel substitution without vehicle and engine modification cannot be undertaken without extensive evaluation according to the economy specific climate and fuel distribution systems. Of course the FFV for ethanol up to 85% substitution is accepted as proven, though only for a limited number of light duty models that have been modified to accept variable ethanol to gasoline ratios.
The non-technical biofuels risks that have emerged in this study are cost of production for Gen-1 biofuels, indirect biomass supply risks from other commodity markets using the same feedstocks, social impacts, environmental impacts of land use change, and biodiversity. Each one of these may also be felt through changes of policy and regulation in the renewable fuel standards for each economy. One, which will have an effect in the short term, will be sustainability criteria that will implicitly address food security, and may well dictate the rate of expansion of biofuels even if the current high prices of oil and food commodities are not maintained. Indeed the biomass supply risk may be exacerbated by more than one aspect of policy and regulation in the food sector, if for example export controls and tariffs (export or import) overlap with the biofuels sector.
Gen-2 biofuels still have considerable technology risks. Few have been proven even at the demonstration scale. Considerable technology and cost risks are associated with the candidate technologies that will use lignocellulosics as feedstock, though the forest and straw based feedstocks will mostly avoid indirect biomass supply risk from commodity competition, except perhaps with forest products in some economies. Even then there will still be a range of social and environmental impacts in land use change and biodiversity which will have to be accommodated.
Some of the end use biofuels in Gen-2 are much more fungible with the existing hydrocarbon fuels and will have less risk in being used in variable fractions of the fuel supplied to the vehicle which may be a benefit in their introduction. These newer fuels, however, will have significant risk with respect to policy and regulation.
The analysis we have undertaken has also demonstrated that expansion of biofuels in the APEC region will also involve biotrade between resource rich economies and the highly urbanized, with limited arable land economies. Biotrade is already significant for the
Ultimately it may be that region wide collaboration on biofuels standards and regulations including sustainability criteria will be the best means of ensuring a balance of opportunity between biofuel producers and consumers while meeting climate, food, and economic development goals. There are also technology collaboration opportunities that could do much to address technology risk especially for Gen-2 fuels, and cooperatively accelerate their implementation.
Concluded
Courtesy: Asia-Pacific Economic Cooperation
